Shafts and rollers
Long shafts, drive shafts and rollers with controlled runout, bearing journals, keyways and ground working surfaces.
View details →Precision turned parts · Türkiye
CNC Turning Service for Precision Turned Parts
Shafts, bushings, flanges and complex rotational parts from prototypes to sliding-head series, supplied with inspection records and export-ready packing.
Up to Ø700 × 4000 mm
Typical ±0.02 mm
1 pc to high-volume (sliding-head)
Prototype in 1–4 weeks
CNC turning service
We translate the diameters, runout, concentricity, threads and surface requirements on your drawing into one production route. CNC turning, C/Y-axis turn-mill, sliding-head production, deep-hole drilling, grinding and honing stay under the same quality plan. A one-off replacement and a repeat series therefore follow the same approved revision and inspection record.
Send Your Drawing for a Quote
Include material, quantity and destination; first technical response within 2 business days.
No account needed · or by email: info@cnc-turkey.com
Part families
Turned parts we make
Pins and bushings
Matched pin-and-bushing pairs with lubrication grooves, press fits, induction-hardened surfaces and honed bores.
View details →
Flanges and rings
Custom parts with bolt circles, sealing faces, internal profiles and controlled datums for welding or assembly.
View details →
Hydraulic rods and piston parts
Hydraulic components requiring pre- and post-chrome machining, threads, seal surfaces and straightness or runout control.
View details →
Long and large-diameter parts
Shafts, tubular parts and heavy rings up to Ø700 mm and 4000 mm long, with steady-rest and deep-hole operations.
View details →
Small high-volume turned parts
Sliding-head production from Ø10–20 mm bar for short-cycle pins, connectors, spacers and repeat precision parts.
Processes and sizes
CNC turning capability
| Process | Size range | Typical tolerance / finish |
|---|---|---|
| CNC turning centres | Up to Ø700 × 4000 mm | Typical ±0.02 mm on turned features |
| Turn-mill with C/Y axis & sub-spindle | Complex rotational parts in one setup | Typical ±0.02 mm without re-clamping error |
| Sliding-head automats | From Ø10–20 mm bar, high volumes | Repeat small diameters and short cycles |
| Deep-hole drilling | Up to 4 m | Axial bores for long shafts and tubular parts |
| Cylindrical/internal grinding & honing | Tight fits and precision bores | Tighter fits; Ra down to 0.4 µm |
Materials & finishes
Materials
C45 42CrMo4 41Cr4 34CrNiMo6 20MnCr5 1.4305 1.4404 EN AW-6082 T6 Brass
Heat treatment & finishes
Induction hardening Case hardening Nitriding Quench & temper Hard chrome Zinc plating Black oxide Anodising (Al)
Documented quality
Quality proof with every shipment
- ✓Every batch is inspected twice: by the producing workshop and by CNC-Turkey, with critical results compared before shipment.
- ✓Every shipment includes a dimensional inspection report and material certificate; EN 10204 3.1 on request.
- ✓Cpk reports are provided on request for series production to verify process capability.
Planning
Lead times by quantity and part size
Machining lead time in weeks, from stock material, before secondary processes.
| Quantity | Small parts (up to Ø30, sliding-head) | Medium parts (Ø30–300, up to 1 m) | Large / long parts (over Ø300 or 1.5 m) |
|---|---|---|---|
| 1–10 (prototype) | 1–2 | 2–3 | 3–4 |
| 10–100 | 2–3 | 3–4 | 4–6 |
| 100–300 | 2–3 | 4–5 | 6–8 |
| 300–600 | 3–4 | 5–6 | On quotation |
| 1,000–5,000 | 3–5 | 6–10 | On quotation |
| 10,000+ | 4–6 (scheduled call-offs) | On quotation | — |
Add for secondary processes
| Heat treatment (quench & temper, induction, case hardening) | +1 week |
| Nitriding | +1–2 weeks |
| Coating (hard chrome, zinc, black oxide) | +1 week |
| Grinding or honing after heat treatment | +0.5–1 week |
| Non-stock material | +2–4 weeks |
| Road freight to Europe | +3–6 days |
High volumes can ship in scheduled batches under a framework order. Send your drawing and annual quantity for a firm lead time — first technical response within 2 business days.
FAQ
CNC turning questions
What is the maximum CNC turning size?
CNC turning capacity extends to Ø700 mm diameter and 4000 mm length. This range covers long shafts, heavy flanges, rings and tubular components.
What tolerances and finishes do you hold?
Typical tolerance on turned features is ±0.02 mm. Cylindrical or internal grinding and honing produce tighter fits and surfaces down to Ra 0.4 µm.
Can you machine long shafts and deep bores?
Yes. We turn shafts up to 4 m with a steady rest and deep-hole drill axial bores to the same maximum length. Runout, straightness and bore-axis checks are recorded in the inspection plan.
Do you produce small turned parts at high volume?
Yes. Sliding-head automats run Ø10–20 mm bar for high-volume pins, connectors, spacers and similar small components. Series control uses a sampling plan and requested Cpk records.
RFQ
Send your drawing for a manufacturing review
Quantity, material, quality requirements and delivery country help us review the appropriate manufacturing and shipment route.
